Double Cone Blender Machine

Here is a highly efficient and versatile industrial blending machine that is specifically designed for mixing granules homogeneously. We at Prime Machinery are engaged in designing and developing next generation mixers and blenders that deliver precision and quality. Owing to our top grade machines we are the best Double Cone Blender Manufacturer Ahmedabad. The Double Cone Blender is predominantly used for rubbing and tumbling of free flowing materials like powder, granules and so on. Using this particular machine enhances the results of dry mixing within a short period of time. Different models are offered with a capacity of 10kg to 300kg. This machine is sued for homogeneous mixing of materials in industries like Food and beverages, Pharmaceutical, Chemical, Agriculture, Cosmetics and many more.

Silent Features

  • The conical shape of both ends enables uniform mixing and easy discharge.
  • All contact parts are made out of SS316 quality material.
  • Maximum care has been taken to ensure safe operation of the unit.
  • Safety reeling, overload protection and emergency shutdown features available.
  • Mirror finish inside and outside the drum.
  • Easy to load and unload the materials
  • Low maintenance and enhanced durability

With outstanding quality and competitive pricing we are a preferred Double Cone Blender Manufacturer Ahmedabad. We also offer customisation of our machines to better meet our client requirements

Description

Model 10 25 50 100 150 200 250 300
Capacity/kg 10 25 50 100 150 200 250 300
Gross Volume 35 80 150 300 450 600 800 900
Working Capacity 10 50 100 200 300 400 500 600
Motor HP0 0.5 1 2 3 5 5 7.5 7.5
Gear Box 1.75" 1.75" 2" 3" 4" 4" 5" 5"
RPM 25 25 30 20 20 20 20 20
Discharge Valve NA NA NA 200 200 250 250 250
Safety Guard NA NA YES YES YES0 YES YES YES
Discharge Height 300 300 450 450 450 450 450 450

Output Depends on Material*

Design as per customer Requirement
